ShanghaiMagnetic latching relay is an automatic switch, which can turn on and off the circuit automatically. Hefei Mycoil Technology Co.,LTD is professional manufacture in designing, producing electronic transformers, choke coils, full range of SMD power inductors, EMI filters, magnetic latching relays. We are ISO9001:2008 certification factory, we have a research team consists of five engineers, we can design filter products to meet customer's requirement and provide custom made service. Magnetic latching relay 100A has many applications, such as lamp controller, complex switch, home appliance and automatic control equipment and electronic devices.
Quick Details
Part No: MCT-BMC-100A Relay |
|
Brand name: MCT |
Contact form: 2A (normal open)/2B (normal closed) |
|
Custom made: Available |
Contact material: silver alloy |
|
Logo: Can be customized |
Contact voltage drop: MAX.15mV |
|
Packing: Carton,can custom |
Contact load (resistance): 100A 250VAC |
|
Certification: ISO9001,ROHS,CE |
Max switching voltage: 250V AC |
|
OEM: Available |
(Max switching power): 25000VA |
|
Shipping: Air, Ship, etc |
Lead time: 25 days after payment |
|
MOQ: Any quantity |
Part Information
Product Name: Magnetic Latching Relay 100A 250VAC For Intelligent Electric Meter
Magnetic Latching Relay Features: Low 100A high contact load capacity. Low 100A high contact load capacity. Low switching power 25 k/VA. Low power consumption. Strong impact resistance, high reliability. Can provide one coil with double coil relay
Applications: Home appliance, automatic control equipment, industrial equipment power supply, other electronic devices.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Details
Contour Chart (unit: mm)
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
