Customized household applicance EMI filters. It has excellent interference suppression for CM and DM. Test voltage(1min): Line to ground:2000VAC. Line to Line:1450VDC. Mainly for Washing Machines, Coffee Machines, Dishwashers, Vacuum Cleaners, Blenders.
brand:
MCTitem no.:
Household Applicance Filtersshipping port:
ShanghaiProfessional filters factory, our home appliance suppression EMI filters -cylindrical power line filter, with unique mounting style. We use high quality materials and high ratio of performance to make filter products. Custom design acceptable, OEM service also available.
Quick Details
|
Part No: Household Applicance Filters |
Brand name: MCT |
|
Rated Voltage: 120/250VAC |
Custom made: Available |
|
Rated Current: 1A~20A |
Logo: Can be customized |
|
Operating Frequency: 50/60Hz |
Packing: Carton, can custom |
|
Temperature range : HPF25/085/21 |
Shipping: Air, Ship, etc |
|
Lead time: 25 days after payment |
MOQ: Any quantity |
|
Certification: ISO9001,ROHS,CE |
OEM: Available |
Part Information
Product Name: Home Appliance Suppression Filter EMI Power Line Filters
Applications: Washing Machines, Coffee Machines, Dishwashers, Vacuum Cleaners, Blenders, Microwave Ovens, Air Conditioners, Vending Machines and other white goods.
Packing details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Details
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
QQ: 2783136957
Contact: Miss Lily Yu
