ShanghaiHefei Mycoil Technology Co.,LTD is professional manufacture in designing, producing electronic transformers, choke coils, full range of SMD power inductors, power EMI noise filters. We are ISO9001:2008 certification factory, we have a research team consists of five engineers, we can design filter products to meet customer's requirement and provide custom made service. We also have quality control department, we use environmental protected materials and high quality components to ensure DC EMI filters more safety and reliability.
DC EMI filter is designed for DC power line. It has excellent differential, high performance and common-mode attenuation. Installation is very convenient. DC EMI filters widely used in kinds of electronic equipments and measuring instruments(DC side): switching power supply, Private Branch Exchange(PBX), data communication, etc.
Quick Details
Part No: MCT7DC-1 |
|
Brand name: MCT |
Rated Voltage: 80VDC/250VDC |
|
Custom made: Available |
Rated Current: 50A~140A |
|
Logo: Can be customized |
Temperature range: HPF 25/085/21 |
|
Packing: Carton,can custom |
Operating Frequency: DC |
|
Certification: ISO9001,ROHS,CE |
Test Voltage(1min): Line to Ground: 350VDC |
|
OEM: Available |
Test Voltage(1min): Line to Line: 500VDC |
|
Shipping: Air, Ship, etc |
Lead time: 25 days after payment |
|
MOQ: Any quantity |
Part Information
Product Name: DC EMI Filters For Switching Power Supply
DC EMI Filters Features: Designed for DC power line. Excellent differential and common-mode attenuation. High performance, easy to install. Custom design acceptable.
Applications: Switching power supply, Private Branch, Exchange(PBX), Data communication, Communication system, Industrial equipment power supply, Medical equipment, Testing equipment.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Details
Dimension: unit :mm
Insertion Loss in dB
Our Service
1.We offer OEM services on all our product lines. Design and manufacture of new models are also available.
2.We accept OEM projects and customer designs and can source products and services for you.
Our strict demands on themselves, continuous improvement and innovation, and strive to meet customers’ demand for high quality products and services.
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
QQ: 2783136957
Contact: Lily Yu
DC EMI filter mainly used in electric power supply, data system, testing equipment, digital system and other consumer electronics. Always designed for DC power line.
EF20 4+4pin coil former. Horizontal EF20 transformer bobbin. Bobbin Size=26.4mmX20.8mmX21.1mm. Bobbin EF20 pin 4+4. Pin pitch=5.0mm. Parallel Distance=21.0mm. EF20 PA66 material transformer bobbin. DIP transformer bobbin.
Customize EE35 transformer. 5+5 pin vertical EE35 coil former. Parallel distance=20.0mm. Pin pitch=5.0mm. EE35 Bobbin Size=32.0mmX25.1mmX26.7mm. DIP pin transformer bobbin. EE35 Phenolic material bobbin.
RM10 vertical type bobbin, DIP pin RM10 6+6 Pins coil former, phenolic RM10 transformer frame. Bobbin Size=28.3mmX21mmX14.9mm. Row distance=18.0mm, pin pitch=3.6mm. Manufacture RM10 main transformer, welcome OEM and customized transformer.
ETD34 Electronic Transformer Iron Clips. UL REC:94V-0. Transformer Clips Material: Stainless Steel 0.4T. Clips Size=38.2mmX10.5mmX9.1mm.
EE42 high frequency bobbin. Horizontal EE42 bobbin pin 5+5. Bobbin Size=46.50mmX29.40mmX34.30mm. Parallel distance=34.70mm. Pin pitch=5.0mm. We can make bobbin tooling. PBT material bobbin.
EE19 flyback transformer bobbin. 4+6 pin vertical coil bobbin. Phenolic material bobbin. Pin Pitch1=2.7mm. Pin Pitch2=3.5mm. Parallel Distance=12mm. DIP bobbin. Size=17.7mmX15.6mmX20.8mm. UL REC:94V-0.
EI35 high frequency transformer. Vertical EI35 7+7 pin bobbin. Bobbin Size=34.0mmX26.0mmX27.4mm.Pin pitch=5.0mm. Parallel Distance=20.0mm. Welcome customized EI35 electronic transformer, widely used in power supplies, lighting, UPS, computers, printers, telecom communication systems, welding machines and other industries.
EE19 horizontal coil bobbin. Double slots 5+5 pins transformer bobbin. Bobbin Size=19.0mmX16.7mmX15.2mm. Parallel distance=12.5mm. Pin Pitch1=3.8mm. Pin Pitch2=5.1mm. We can make bobbin tooling for customer.
5+5 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.5mm Parallel Distance=8.5mm
EDR28 5+2 pins transformer bobbin. Phenolic EDR28 transformer bobbin. Pin Pitch1=3mm. Pin Pitch2=4mm. EDR28 LED transformer bobbin. Bobbin Size=42.5mmX15mmX7.4mm. DIP L pin /SMD bobbin. UL REC:94V-0
EF20 DIP coil former, 5+5 pins vertical EF20 transformer frame, phenolic material EF20 bobbin. Pin pitch=3.8mm, Bobbin Size=22.0mmX13.5mmX21.10mm. Parallel distance=10.10mm. We manufacture final transformers, custom design and OEM transformers also acceptable.
